Assault Rifles
5.56x45 mm and 7.62x39 mm AR-M8F
5.56x45 mm ARSENAL Assault Rifles AR-M8F small-size with folding butt
NSN: 1005-50-001-1741
7.62x39 mm ARSENAL Assault Rifles AR-M8F small-size with folding butt
NSN: 1005-50-001-1742
The 5.56 mm AR-M8F and 7.62 mm AR-M8F are highly effective automatic weapons, used as armament of army troops, reconnoitring detachments, special antiterrorist and police forces, and security services.
Main Features:
- Gas operated automatic rifle;
- Fire mode – single, automatic;
- Hot-die forged and milled receiver for increased durability and service life;
- Chromium plated Barrel bore and chamber;
- FRP (fiber glass reinforced polycaproamide) Lower and Upper hand guards, Pistol grip and 30-round Magazine – heat/cold resistant with antiglare matte finish;
- Right-side folding tubular steel enforced butt with a quick release/lock mechanism;
- Ambidextrous Safety Lever for rapid fire mode switchover;
- Self-illuminated Tritium sights for faster target acquisition at low-light conditions (optional);
- Side mounted scope rail for dovetail based sight carriers with sighting devices;
- Provision for attachment of 40x46mm ARSENAL UBGL-M6, UBGL-M8 and 40mm ARSENAL UBGL-1 Underbarrel Grenade Launchers, and firing with them.
Optional Extras (Paid Separately):
- Black polymer magazine for 40 cartridges; ( for 7.62x39 mm )
- 20/30-round translucent polymer magazine; ( for 5.56x45 mm )
- Front sight adjusting kit (in the ratio 1:10);
- Set for magazines coupling;
- Blank fire attachment;
- Knife-scissors.
- Silencer
 Specifications |
AR-M8F | AR-M8F |
| Calibre, mm | 5.56 | 7.62 |
| Cartridge, mm | 5.56 x 45 | 7.62 x 39 |
| Fire mode | single, automatic | single, automatic |
| Rate of fire, rounds/min | 600 | 600 |
| Practical rate, rounds/min | ||
| - automatic fire | up to 100 | up to 100 |
| - single fire | up to 40 | up to 40 |
| Muzzle velocity, m/s | 650 | |
| - bullet type M 193 | 880 | - |
| - bullet type SS 109 | 830 | - |
| Sighting range, m | up to 500 | up to 500 |
| Maximum firing range, m | 1100 | 1100 |
| Effective firing range, m | 400 | 350 |
| Magazine capacity, rounds | 30 | 30 |
| Barrel length, mm | 320 | 320 |
| Sight radius, mm | 278 | 278 |
| Overall length, mm | ||
| - with extended butt | 880 | 880 |
| - with folded butt in travelling position | 630 | 630 |
| Weight, kg: | ||
| - rifle with empty magazine | 3.75 | 3.75 |
| - loaded magazine | 0.58 | 0.72 |
| System life, rounds | 15 000 | 15 000 |
| Principle of function | gas operated | gas operated |
 ACCESSORIES |
|
Cleaning rod Sling Box with accessories (brush, drift, slush brush (cal. 5.56)/ scourer (cal. 7.62), screwdriver) Magazine 4 pcs Bag for magazines Oil can |
 Packing |
|
| Number of rifles in one wooden case | 10 |
| Case dimensions, mm | 1380 x 530x 387 |
| Gross Weight of the wooden case, kg | 85 |
| Volume of the wooden case, m3 | 0.28 |
