Small Arms Ammunition

7.62x39 mm cartridges

Small Arms Ammunition

7.62x39 mm Rounds

Specifications

Caliber,[mm] Case Bullet type Bullet weight,[g] Primer type Average bullet velocity,[m/s] Average chamber pressure,[MPa]
7.62x39 Steel FMJ/SC Bimetal jacket +steel core 7.9 "€œBerdan" V25-717,5 274,6
7.62x39 Steel FMJ/LC Bimetal jacket+lead core 7,93 "€œBerdan" V25-717,5 274,6
7.62x39 Bimetal FMJ/SC Bimetal jacket+steel core 7,9 "€œBerdan" V25-717,5 274,6
7.62x39 Steel API Bimetal jacket, armour piercing incendiary 7,31 -7,91 "€œBerdan" V25-725 - 740 274,6
7.62x39 Bimetal Tracer T-45 ( T ) 7,58 "Berdan" V25-717,5 274,6
7.62x39 Steel Tracer T-45 ( T ) 7,58 "€œBerdan" V25-717,5 274,6
7.62x39 Bimetal Blank - "€œBerdan" - -
7.62x39 Steel Blank - "€œBerdan" - -
7.62x39 Bimetal SP / Soft Point / Bimetal jacket+lead core 9,6 "€œBerdan" V25-620 274,6
7.62x39 Bimetal HP / Hollow point /
Bimetal jacket+lead core
9,65 €"Berdan" V25-620 274,6
7.62x39 Bimetal FMJ/LC Bimetal jacket+lead core 7,93 "€œBerdan" non-corrosive V25-717,5 274,6
Weapons:
ARSENAL AR-M family, ARSENAL LMG, LMG-F, AKš-47, AKS-47, RPK, RPKS, RPD, etc.
Packing:
Caliber, mm Cardboard, pcs. Metal box, pcs. Case, pcs. Case dimesions, mm Case gross weight, kg Case volume, m3
7.62x39 ball 20 700 1400 488x353x151 30 0.026
7.62x39 API 20 700 1400 488x353x151 30 0.026
7.62x39 tracer 20 700 1400 488x353x151 30 0.026
7.62x39 blank 20 740 1480 488x353x151 20 0.026
